Product Description:

Our 12-Strand PP Rope made by UHMWPE or Spectra® fiber

12-Strand UHMWPE Rope
12-Strand UHMWPE Rope
12-Strand UHMWPE Rope
12-Strand UHMWPE Rope
  • Specifications
  • Overview
  • Technical Comparison
Diameter Circle Weight Breaking Strength
mm inch inch LBS/100FT KGS/100M lbs ton
4 1/8 1/2 0.7 1.0 2860 1.30
5 3/16 9/16 1.3 1.8 4900 2.20
6 1/4 3/4 1.6 2.4 7000 3.19
7 9/32 21/25 2.3 3.2 8800 4.00
8 5/16 1 2.7 4.0 13000 5.90
10 3/8 1-1/8 4.0 5.6 19600 8.90
11 7/16 1-1/4 4.2 6.2 23800 10.80
12 1/2 1-1/2 6.4 8.9 30400 13.80
14 9/16 1-3/4 7.9 11.8 39900 18.10
16 5/8 2 10.2 15.2 46500 21.10
18 3/4 2-1/4 13.3 19.8 64300 29.20
22 7/8 2-3/4 19.6 29.2 88500 40.20
24 1 3 21.8 32.4 107800 49.00
26 1-1/16 3-1/4 27.5 40.9 123200 56.00
28 1-1/8 3-1/2 31.9 47.5 142400 64.70
30 1-1/4 3-3/4 36.2 53.9 165000 75.00
32 1-5/16 4 41.8 62.2 184000 83.60
34 1-3/8 4-1/8 45.0 67.0 202900 92.20
36 1-1/2 4-1/2 51.7 76.9 222200 101.00
40 1-5/8 5 63.5 88.0 268400 122.00
44 1-3/4 5-1/2 77.8 107.8 321200 146.00
48 2 6 91.2 126.4 365200 166.00
52 2-1/8 6-1/2 109.1 151.2 431500 196.12
56 2-1/4 7 116.0 173.0 464700 211.20
60 2-1/2 7-1/2 145.0 201.0 561300 255.10
64 2-5/8 8 163.0 226.0 593100 269.59
68 2-3/4 8-1/2 187.0 258.5 706300 321.02
72 3 9 210.0 291.0 787600 358.00
80 3-1/4 10 255.0 353.0 935000 425.00
Features:
.Material:UHMWPE or Spectra® fiber
.Construction:8&12-Strand
.Specific Gravity:0.975g/m2 (float)
.Elongation:3.5% at break
.Melting Point:145℃
.Abrasion Resistance:Excellent
.UV and Chemicals Resistance:good

Application:
primary mooring lines for various vessels
Wire replacements in commercial fishing trawl systems
Face and win wires for push tugs
Tractor tug winch lines
Emergency and seismic tow lines
