Product Description:

SHANGHAI JINLI SPECIAL ROPE CO.,LTD is one of the toppest Classic Synthetic Winch Rope in China.During these years of exporting , SHANGHAI JINLI SPECIAL ROPE CO.,LTD now has rich experience in the worldwide markets

Classic Synthetic Winch Rope
Classic Synthetic Winch Rope
Classic Synthetic Winch Rope
Classic Synthetic Winch Rope
  • Specifications
  • Overview
  • Personalisation
Diameter Breaking Strength Recommended Winch Rating
mm inch In UHMWPE Fiber In Spectra® Fiber In UHMWPE Fiber In Spectra® Fiber
5 3/16 4,900 lbs(2,220 kg) 6,200 lbs(2,810 kg) 1,500-3,500 lbs(680-1,590 kg) 1,500-4,300 lbs(680-1,960 kg)
6 1/4 7,000 lbs(3,180 kg) 8,400 lbs(3,810 kg) 2,100-4,900 lbs(950-2,220 kg) 2,100-5,880 lbs(950-2,660 kg)
8 5/16 12,300 lbs(5,580 kg) 14,000 lbs(6,380 kg) 6,000-8,000 lbs(2,720-3,630 kg) 6,000 - 9,100 lbs(2,720-4,140 kg)
10 3/8 17,600 lbs(7,980 kg) 19,400 lbs(8,810 kg) 8,000-11,600 lbs(3,630-5,260 kg) 8,000 - 12,600 lbs(3,630-5,720 kg)
11 7/16 21,500 lbs(9,800 kg) 23,800 lbs(10,800 kg) 10,000-15,000 lbs(4,540-6,800 kg) 10,000 - 15,700 lbs(4,540-7,130 kg)
12 1/2 27,000 lbs(12,300 kg) 30,600 lbs(13,900 kg) 12,200-17,500 lbs(6,100-7,950 kg) 12,200 - 18,000 lbs(6,100-8,160 kg)
14 9/16 36,500 lbs(16,500 kg) 39,900 lbs(18,100 kg) 18,000-24,000 lbs(8,160-10,890 kg) 18,000 - 26,000 lbs(8,160-11,810 kg)
The New Synthetic Lines Ara.
Steel-wire winch rope have been around for more than 150years, so who can instead it. That’s a question we want to find it. Last century there’re many things change so fast, it’s time to consider how synthetic winch rope can instead steel-wire winch rope. 14% of the wire rope’s weight of case of the same breaking strength, so you save space on the drum and the winch works more efficiently.
Honeywell Spectra® is our best partner, all of our original material Spectra® fiber come from USA. We also can provide the Spectra certificate in business deal according to your arrangement.

Advantages

Over Other Synthetic Winch Ropes

• Highest strength synthetic winch rope
• We cooperate with Honeywell Spectra®
• Use smaller diameter line without sacrificing strength - either gain winch efficiency or gain winch rope length
• Spliced by our engineers
• Good after-service
• Made in Shanghai with good price

Over Steel Wire Rope

• Safer than steel wire rope
• Stronger than steel wire rope
• Extremely lightweight makes it easy to use
• Floats in water
• Torque-free
• No more cut hands from wire splinters or burrs
• Will not kink like steel wire rope
• Will not rust
