Product Description:

Our 3-Strand Polysteel Rope made by super Dan PP.

3-Strand Polysteel Rope
3-Strand Polysteel Rope
3-Strand Polysteel Rope
3-Strand Polysteel Rope
  • Specifications
  • Overview
  • Technical Comparison
Diameter Circle 3 Strand Polysteel Rope
Weight Breaking Strength
mm inch inch kg/220M ton
4 5/32 1/2 1.32 0.25
6 1/4 3/4 3.74 0.72
8 5/16 1 6.60 1.27
10 3/8 1-1/8 9.90 1.87
12 1/2 1-1/2 14.30 2.65
14 9/16 1-3/4 20.00 3.66
16 5/8 2 25.30 4,53
18 3/4 2-1/4 32.50 5.78
22 7/8 2-3/4 48.40 8.35
24 1 3 57.00 9.75
28 1-1/8 3-1/2 78.00 12.80
32 1-1/4 4 101.00 16.20
36 1-1/2 4-1/2 129.00 20.20
40 1-19/32 5 158.00 24.60
44 1-3/4 5-1/2 194.00 29.50
48 1-7/8 6 229.00 34.30
52 2-1/16 6-1/2 268.00 39.70
Features:
. Material:super Dan PP.
.Construction:3,8 &12-strand
.Specific Gravity:0.91g/m2
.Elongation:17-21% at break
.Melting Point:165℃
.Abrasion Resistance:Excellent
.UV and Chemicals Resistance:good

Application:
Wire rope replacement
Secondary mooring ropes
Barge and dredge working ropes
Tractor tug winch ropes
General working ropes
Heavy loft slings
Lowering/lifting ropes
Towing ropes
Working ropes
Safety ropes
Hardware ropes
