Product Description:

SHANGHAI JINLI SPECIAL ROPE CO.,LTD is one of the toppest 3-Strand PP Rope in China.During these years of exporting , SHANGHAI JINLI SPECIAL ROPE CO.,LTD now has rich experience in the worldwide markets

3-Strand PP Rope
3-Strand PP Rope
3-Strand PP Rope
3-Strand PP Rope
  • Specifications
  • Overview
  • Technical Comparison
Diameter Circle 3 Strand
Weight Breaking Strength
mm inch inch kg/220M ton
4 5/32 1/2 1.32 0.21
6 1/4 3/4 3.74 0.60
8 5/16 1 6.60 1.06
10 3/8 1-1/8 9.90 1.56
12 1/2 1-1/2 14.30 2.21
14 9/16 1-3/4 20.00 3.05
16 5/8 2 25.30 3.78
18 3/4 2-1/4 32.50 4.82
22 7/8 2-3/4 48.40 6.96
24 1 3 57.00 8.13
28 1-1/8 3-1/2 78.00 10.70
32 1-1/4 4 101.00 13.50
36 1-1/2 4-1/2 129.00 16.90
40 1-19/32 5 158.00 20.50
44 1-3/4 5-1/2 194.00 24.60
48 1-7/8 6 229.00 28.60
52 2-1/16 6-1/2 268.00 33.10
Features:
Material:PP Monofilament
.Construction:3,8 &12-strand
.Specific Gravity:0.91g/m2
.Elongation:17-21% at break
.Melting Point:165℃
.Abrasion Resistance:Excellent
.UV and Chemicals Resistance:good

Application:
Wire rope replacement
Secondary mooring ropes
Barge and dredge working ropes
Tractor tug winch ropes
General working ropes
Heavy loft slings
Lowering/lifting ropes
Towing ropes
Working ropes
Safety ropes
Hardware ropes
