Product Description:

Our 8-Strand Polysteel Rope made by super Dan PP.

8-Strand Polysteel Rope
8-Strand Polysteel Rope
8-Strand Polysteel Rope
8-Strand Polysteel Rope
  • Specifications
  • Overview
  • Technical Comparison
Diameter Circle 8 Strand Polysteel Rope
Weight Breaking Strength
mm inch inch kg/220M ton
36 1-1/2 4-1/2 132.0 20.2
40 1-19/32 5 165.0 24.6
44 1-3/4 5-1/2 202.0 29.5
48 1-7/8 6 245.0 34.3
52 2-1/16 6-1/2 285.0 39.7
56 2-1/4 7 316.0 46.6
60 2-3/8 7-1/2 365.0 53.1
64 2-1/2 8 412.0 59.7
68 2-11/16 8-1/2 468.0 67.1
72 2-7/8 9 525.0 74.4
80 3-5/32 10 642.0 90.8
88 3-7/16 11 780.0 109.1
96 3-13/16 12 931.0 128.6
100 4 12-1/2 1009.0 139.1
104 4-1/8 13 1086.0 149.4
112 4-7/16 14 1255.0 170.2
120 4-3/4 15 1430.0 197.2
Features:
. Material:super Dan PP.
.Construction:3,8 &12-strand
.Specific Gravity:0.91g/m2
.Elongation:17-21% at break
.Melting Point:165℃
.Abrasion Resistance:Excellent
.UV and Chemicals Resistance:good

Application:
Wire rope replacement
Secondary mooring ropes
Barge and dredge working ropes
Tractor tug winch ropes
General working ropes
Heavy loft slings
Lowering/lifting ropes
Towing ropes
Working ropes
Safety ropes
Hardware ropes
