Product Description:

Our Double Braided Nylon Rope made by Nylon6 or Nylon66( Polyamide )

Double Braided Nylon Rope
Double Braided Nylon Rope
Double Braided Nylon Rope
Double Braided Nylon Rope
  • Specifications
  • Overview
  • Technical Comparison
Diameter Circle Double Braided Nylon Rope
Weight Breaking Strength
mm inch inch g/m kg/220M kn ton
6 1/4 3/4 24 73.7 122.60 12.51
8 5/16 1 39 101.2 162.80 16.61
10 3/8 1-1/8 55 130.9 208.90 21.31
11 7/16 1-1/4 76 163.2 272.70 27.82
12 1/2 1-1/2 98 201.3 329.60 33.62
14 9/16 1-3/4 138 239.8 392.40 40.00
16 5/8 2 179 290.4 453.00 46.00
18 3/4 2-1/4 223 330.0 525.80 53.60
22 7/8 2-3/4 335 73.7 122.60 12.51
24 1 3 460 101.2 162.80 16.61
28 1-1/8 3-1/2 595 130.9 208.90 21.31
32 1-1/4 4 742 163.2 272.70 27.82
36 1-1/2 4-1/2 915 201.3 329.60 33.62
40 1-19/32 5 1090 239.8 392.40 40.00
44 1-3/4 5-1/2 1320 290.4 453.00 46.00
48 1-7/8 6 1500 330.0 525.80 53.60
52 2-1/16 6-1/2 1790 393.8 608.00 62.00
56 2-1/4 7 2005 441.1 691.00 70.00
60 2-3/8 7-1/2 2260 497.2 775.00 79.00
64 2-1/2 8 2540 558.8 868.00 88.00
68 2-11/16 8-1/2 2840 624.8 971.00 99.00
72 2-7/8 9 3490 767.8 1177.00 120.00
80 3-5/32 10 4200 924.0 1422.00 145.00
88 3-7/16 11 4395 966.9 1488.00 151.00
96 3-13/16 12 5000 1100.0 1687.00 172.00
100 4 12-1/2 5390 1185.8 1834.00 187.00
104 4-1/8 13 5860 1289.2 1981.00 202.00
112 4-7/16 14 6740 1482.8 2285.00 233.00
120 4-3/4 15 7740 1702.8 2609.00 266.00
Features:
. Material:Nylon
.Construction:Double braided
.Specific Gravity:1.14g/m2
.Elongation:16-25% at break
.Melting Point:215℃
.Abrasion Resistance:Excellent
.UV and Chemicals Resistance:good

Application:
Wire rope replacement
Secondary mooring ropes
Barge and dredge working ropes
Tractor tug winch ropes
General working ropes
Heavy loft slings
Lowering/lifting ropes
Towing ropes
Working ropes
Safety ropes
Hardware ropes
