Product Description:

As the largest Double Braided UHMWPE Rope manufacturer in china, SHANGHAI JINLI SPECIAL ROPE CO.,LTD sales quality Double Braided UHMWPE Rope to customers all over the world.

Double Braided UHMWPE Rope
Double Braided UHMWPE Rope
Double Braided UHMWPE Rope
Double Braided UHMWPE Rope
  • Specifications
  • Overview
  • Technical Comparison
Diameter Circle Weight Breaking Strength
mm inch inch g/m kg/220M kn ton
20 13/16 2-1/2 240.0 52.8 244.00 24.90
22 7/8 2-3/4 290.0 63.8 307.00 31.30
24 1 3 340.0 74.8 362.00 36.90
26 1-1/16 3-1/4 400.0 88.0 424.00 43.20
28 1-1/8 3-1/2 460.0 101.2 494.00 50.40
30 1-1/4 3-3/4 530.0 116.6 573.00 58.40
32 1-5/16 4 600.0 132.0 662.00 67.50
34 1-3/8 4-1/8 680.0 149.6 742.00 75.70
36 1-1/2 4-1/2 770.0 169.4 821.00 83.70
40 1-5/8 5 950.0 209.0 1210.30 123.50
44 1-3/4 5-1/2 1168.0 107.8 1429.82 145.90
48 2 6 1368.0 126.4 1629.74 166.30
52 2-1/8 6-1/2 1641.0 151.2 1929.62 196.90
56 2-1/4 7 1900.0 173.0 2219.70 226.50
60 2-1/2 7-1/2 2168.0 201.0 2509.78 256.10
64 2-5/8 8 2441.0 226.0 2790.06 284.70
68 2-3/4 8-1/2 2791.0 258.5 3150.21 321.30
72 3 9 3141.0 291.0 3510.36 358.20
80 3-1/4 10 3809.0 353.0 4169.90 425.50
88 3 11 4582.0 291.0 4919.60 502.00
96 3-1/4 12 5391.0 353.0 5689.88 580.60
Features:
.Material:UHMWPE or Spectra® fiber/Polyester
.Construction:Double braided
.Specific Gravity:0.975g/m2 (float)
.Elongation:3.5% at break
.Melting Point:150℃/265℃
.Abrasion Resistance:Excellent
.UV and Chemicals Resistance:good

Application:
Single or split drum winch
primary mooring lines for various vessels
Wire replacements in commercial fishing trawl systems
Deep water lifting projects
Tractor tug winch lines
Primary mooring lines for single or split drum winches
