Product Description:

SHANGHAI JINLI SPECIAL ROPE CO.,LTD is one of the toppest Mobile Cranes Pulling Rope in China.During these years of exporting , SHANGHAI JINLI SPECIAL ROPE CO.,LTD now has rich experience in the worldwide markets

Mobile Cranes Pulling Rope
Mobile Cranes Pulling Rope
Mobile Cranes Pulling Rope
Mobile Cranes Pulling Rope
  • Specifications
  • Overview
  • Compare
Diameter Circle Weight Breaking Strength
mm inch inch LBS/100FT KGS/100M lbs ton
4 1/8 1/2 0.7 1.0 2860 1.30
5 3/16 9/16 1.3 1.8 4900 2.20
6 1/4 3/4 1.6 2.4 7000 3.19
7 9/32 21/25 2.3 3.2 8800 4.00
8 5/16 1 2.7 4.0 13000 5.90
10 3/8 1-1/8 4.0 5.6 19600 8.90
11 7/16 1-1/4 4.2 6.2 23800 10.80
12 1/2 1-1/2 6.4 8.9 30400 13.80
14 9/16 1-3/4 7.9 11.8 39900 18.10
16 5/8 2 10.2 15.2 46500 21.10
18 3/4 2-1/4 13.3 19.8 64300 29.20
22 7/8 2-3/4 19.6 29.2 88500 40.20
24 1 3 21.8 32.4 107800 49.00
26 1-1/16 3-1/4 27.5 40.9 123200 56.00
28 1-1/8 3-1/2 31.9 47.5 142400 64.70
30 1-1/4 3-3/4 36.2 53.9 165000 75.00
32 1-5/16 4 41.8 62.2 184000 83.60
34 1-3/8 4-1/8 45.0 67.0 202900 92.20
36 1-1/2 4-1/2 51.7 76.9 222200 101.00
40 1-5/8 5 63.5 88.0 268400 122.00
JINLI Mobile Cranes Pulling Rope can improving crane operations for better. Now, most of people hear about synthetic rope instead of wire rope and working better than it. The world has changed a lot last century, we also consider synthetic rope how to working on crane. It has lower weight, increase safety, and operate faster.

Features

Extreme strength-to-weight ratio
• lightweight and flexible for easy handing
• safer than wire ( low recoil)
• Slimmer synthetic rope maintains higher WLL
• Save weight for Cranes
• Available Colors: Purple , Red, Orange, Safety Green, Military Green, Yellow, Blue, Light Blue, Black, Gray, Pink
• Traceable ID tags
